1. Available in sizes from DN15 to DN50
2. Applicable medium: water, water + ethylene glycol, deionized water and other liquids
3. Measurement accuracy: ±2%
4. Virtually no pressure loss
5. Analog signal and bus communication are supported
6. Equipped with a temperature sensor
7. Optional pressure sensor
8. An external temperature probe is available as an option for heat metering
9. Bubble detection function
10. Glycol concentration measurement and compensation are supported

Downloads

ALSONIC Brass DN15-DN50 Specification Sheet ALSONIC Brass DN15-DN50 Specification Sheet2

Specifications

Medium: water, water + glycol, deionized water and many other liquids
Measurement accuracy: ±2% of reading
Pressure: 0 - 16 bar
Operating temperature: -20 to 100°C
Wetted material: Brass CW724R, PPS, EPDM
Connection: BSPP Male Thread (Flat Sealed)
Output signal: Pulse, 0-5 V, MODBUS
Function:
• Flow measurement
• Temperature measurement
• Pressure measurement (optional)
• Calorie calculation (optional)
