R32 And R454 Refrigerant Infrared Sensor

The NDIR technology used in Senseair Sunlight products ensures that the sensor is protected from poisoning, while the optical solid-state design makes it physically rugged and resistant to vibration. With our automatic baseline correction feature, you can install and forget about the sensor and maintain high accuracy over a lifetime of more than 15 years.

Product Features

1. IEC 60079-29-1 compliant
2. Complies with IEC and UL 60335-2-40 standards for sensing components
3. Miniature size
4. Fast response time
5. Maintenance-free design
6. Long-term stability
7. Long service life
8. Anti-poisoning interference
9. Individually calibrated
10. Very low power consumption
11. Suitable for mass production

Downloads

Sunlight R32 & R454 A/B/C Specification Sheet Sunlight R32 & R454 A/B/C Specification Sheet2

Specifications

How it works: Non-Dispersive Infrared (NDIR)
Detection gas: R32, R454 A/B/C
Measurement range: 0–50% LFL
Accuracy: ±2.5% LFL
Working conditions: -40°C to 70°C, 0–95% RH
Warm-up time: 0 seconds
Response time: <12 seconds
Power supply: 3.05 - 5.5 V
Peak current: 94 mA
Average current: 1-94 μA
Communication interface: I2C, UART
Output: Digital signal
Complies with: IEC 60079-29-1, IEC 60335-2-40 7th Edition, UL 60335-2-40 4th Edition
Maintenance Requirements: Periodic Zero Correction or Automatic Baseline Correction (ABC Correction)
Service life: more than 15 years
Dimensions: 34 x 21 x 12 mm (L x W x H)
Weight: 5 g
Storage conditions: -40°C to 85°C
