1. Suitable for pure hydrogen H2 and hydrogen mixtures
2. Measurement accuracy: ±3%
3. Mass flow determination
4. Circulating concentration determination of H2-N2-H2O
5. Non-stiff steel sensor housing
6. Supports CAN and Modbus communication
7. Built-in temperature and pressure sensors
8. Built-in humidity sensor
9. Suitable for dry and wet gases, humidity up to 100%RH
10. Strong resistance to impurities and dirt

Downloads

Hydrogen Flow Meter Specification Sheet Hydrogen Flow Meter Specification Sheet2

Specifications

Medium: Hydrogen and mixed gases (e.g. H2/N2/H2O)
Measurement accuracy: ±3% of reading
Operating pressure: 0.8 - 15 bar(a)
Operating temperature: -20 - 85°C
Wetted materials: Stainless steel, silicon dioxide, FKM
Output signal: CAN-Bus, Modbus
Function:
• Flow measurement
• Temperature measurement
• Pressure measurement
• Humidity measurement
