PMPSW400

This series of electronic pressure switches and sensors is designed for industrial applications requiring high precision and the ability to operate across a wide temperature range. Specifically engineered for gas and liquid pressure measurement, these devices are widely used in pneumatics, hydraulics, and process engineering. The PMP-SW400 model supports zero-point calibration via onboard push buttons and allows switching point configuration within a range of 1% to 99% of the measurement span.

Product Features

Optimized for medium to high-pressure measurement, this device is suitable for both gas and liquid media, features microprocessor-based signal processing, supports pressure offset correction, and allows switch point configuration via integrated push buttons.

Downloads

Specification Sheet

Specifications

Enter the parameters
project	illustrate
Type of pressure	Gauge
Mechanical connection*	G 1/4" Form E; 1/4"-18 NPT
Wetted parts	Stainless steel 316L or 17-4 PH
Locking torque	Approx. 25 nm
Enclosure size	100×66×45 mm aluminium housing with transparent PC cover
Switching output characteristics
project	illustrate
Electrical connections	PCB mounting terminal block, 3-pole, via PG M16 outlets, conductor max. 1.5 mm² / AWG16
Output 1	4… 20 mA (three-wire); 0/1… 5 V； 0… 10 V
Supply voltage	18… 28 V DC； 10… 16 V DC (on request).
Load resistance	≥ 2 kΩ (voltage output).
Output 2	2 sets of relay outputs, 1x Form C each
Switching point range	1 ~ 99% measurement range (each relay is set independently).
Hysteresis point range	1 ~ 99% measurement range (each relay is set independently).
Maximum switching current*	30 VDC / 1 A or 30 VAC / 0.5 A
Reaction time	100 ms
Analog output characteristics
project	illustrate
Accuracy (25°C).	Typical ≤ ±0.5% F.S
Overall accuracy (-10°C to 80°C).	Typical ≤ ±2% F.S
Long-term stability	≤±0.2% F.S per annum (under reference conditions).
Operating ambient temperature	-20°C ～ +80°C
Medium temperature	-25°C ～ +120°C
Storage temperature	-20°C ～ +80°C
Ingress protection	IP65
Reset to zero	Manual setting via on-screen buttons (see page 4 for details)
Electrical protection
project	illustrate
Reverse polarity protection	Yes
CE marked	Complies with 89/336/EWG electromagnetic compatibility
other	—
weight	Approximately 250 g
