Alcohol Sensor
The purpose of the Senseair A ONE is to measure the concentration of alcohol in human exhalation. This product is designed to be integrated into alcohol breath detection systems to reduce the risk of drunk driving.
Product Features
1. Highly diluted breath samples are accepted
2. No mouth bite tube required
3. Hygienic, touch-free system
4. Short measurement times
5. Can be mounted on the rear panel to keep it clean
Downloads
Specifications
- How it works: Non-Dispersive Infrared (NDIR)
- Detection gas: Ethanol
- Measuring range: 0–3.2 mg/L
- Accuracy: ±7.5% of reading or ±0.015 mg/L, whichever is greater
- Operating humidity range: <95% RH
- Operating temperature range: -40°C to 85°C
- Warm-up time: <15 seconds
- Power supply: 12 V DC
- Peak current: 10 A
- Average current: <0.8 A
- Communication interface: CAN
- Compliant standards: SAE-J3214
- Dimensions: 174.5 x 56 x 28 mm (L x W x H)
- Weight: 240 g
-
Model：A ONE
