Ultrasonic Micro Flow Meter

Ultrasonic Micro Flow Meter

The second generation of miniature flow meters with higher accuracy, extended measuring range, push-in connector connection and state-of-the-art communication interface.

Product Features

1. Suitable for water, milk, coffee, soft drinks and many other liquids
2. Measurement accuracy: ±2%
3. Push-in fitting connection, U and Z design
4. Designs and materials that comply with food safety certifications
5. Analog signals are supported to communicate with the bus
6. Built-in temperature sensor
7. Ultrasonic high-speed temperature measurement
8. It has a bubble detection function

Downloads

Specifications

  • Medium: Water, milk, coffee, soft drinks and many other liquids
  • Measurement accuracy: ±2% of reading
  • Pressure: 0 - 10 bar
  • Operating temperature: 0 - 105°C
  • Wetted Material: PPS, Stainless Steel 1.4301, Silicone Rubber (VMQ)
  • Output signals: Pulse, 0 - 5 V, MODBUS, I²C
  • Function:
    • Flow measurement
    • Temperature measurement
  • Model:Micro Flow Meter 2nd Gen
