Differential Pressure Metering

A series of high-precision differential pressure transmitters for industrial use
Designed to meet the high accuracy requirements over a wide temperature range, it is used to measure pressure differences in air and liquids. These differential pressure transmitters are widely used in pneumatics, hydraulics and process engineering.
The fully digital solution allows the measurement range to be scaled from 1:1 to 1:10 depending on the ratio of line pressure and differential pressure. The differential pressure transmitter is equipped with zero point correction, range adjustment, measurement filtering, and pressure interface polarity switching via an additional service box and PC software, providing flexibility for a wide range of industrial applications.

Product Features

1. High media tolerance
2. Microprocessor signal conditioning
3. High signal accuracy, better than 0.5% of full-scale signals
4. Signal scaling via PC software is supported
5. Support tool or PC software for zero setting
6. Signal filtering function (customizable)
7. Oil-filled sensors for corrosive media applications

Downloads

PMP-D131 Specification Sheet

Specifications

Best suited for: In-line configurable, low and medium pressure, aggressive media
Pressure range: 70 mbar – 100 bar
Diaphragm material: Steel 316L
Sensing element structure: with internal diaphragm
Pressure Type: Gauge Pressure, Seal Reference Pressure, Absolute
