Ammonia Gas Sensor

ECtox ammonia detection devices feature a durable EC Sense solid electrolyte NH3 sensor offering long life, selectivity, and high-precision detection. Unlike common sensors that degrade quickly in high ammonia environments, ECtox maintains performance and longevity. Using a specific electrochemical reaction and a sample pump, it measures a wide ammonia concentration range without calibration. The adaptable sampling system compensates for variations in diffusion and convection speeds due to environmental factors. Output via RS485 (Modbus) allows easy integration with gas detectors, DCS, PLC, or wireless systems.

Product Features

1. Intelligent measurement system
2. It can be operated continuously in the background in high ammonia concentration environments
3. Combined with intelligent algorithms, it has better environmental adaptability
4. The detection accuracy is higher and the zero point is stable
5. Equipped with a pump, there is no need to calibrate NH3 gas
6. New microcircuit design, strong anti-electromagnetic interference ability
7. Unaffected by temperature and humidity
8. RS485 output, 5-12V DC power supply
9. Non-sturbium steel shell, waterproof and dustproof, anti-corrosion
10. Measurable gas detection range, from ppb to higher ppm levels
11. Continuously monitor itself for fault conditions: sensors, pumps, power supplies, etc
12. RoHS compliant and eco-friendly
13. Self-monitoring sensor function

Downloads

ECtox-NH3-500 Specification Sheet ECtox-NH3-500 Specification Sheet2

Specifications

Detection range: 0 – 500 ppm
Resolution: 0.1 ppm
Reaction time: 1 to 10 minutes (depending on the selected measurement cycle)
Output: RS485 (Modbus protocol), baud rate: 9600, 4Pin Lemo cable, standard length 10 m (other lengths on request)
Operating pressure: Atmospheric pressure ± 10%, maintain a stable pressure
Operating voltage: 5 – 12V DC
Temperature range: -40°C ~ +85°C (High temperature type: -40°C ~ +200°C)
Humidity Range: 10% ~ 95%
Weight: 450 g (with 10 m Lemo cable: 400 g)
Dimensions (with sensor): 159 mm x 43 mm
