Inline Gas Density Meter

This MEMS-based sensor measures gas density in gas lines or storage tanks using a tuning fork oscillator. The natural frequency varies with gas density, while integrated components monitor pressure and temperature. Compact (33 mm diameter, 63 mm length), it’s easy to install and comes with a filter to prevent contamination. Data is transmitted via RS485, and the sensor provides real-time measurements with a 5-second response time for stable results.

Product Features

1. Measurement parameters
2. Density: in kg/m³
3. Temperature: In °C
4. Pressure: Absolute pressure in bar
5. Derived measurement parameters (configurable according to customer requirements):
6. Concentration of binary gas mixture: ideal volume percentage (= molar percent) in %
7. Average molar mass
8. Customer-defined measurement parameters
9. Applicable media:
10. Hydrogen (H₂)
11. Helium (He)
12. Nitrogen (N₂)
13. Oxygen (O₂)
14. Carbon dioxide (CO₂)
15. Argon (Ar)

Downloads

DGF-I1 Specification Sheet

Specifications

Density Measurement Range:
0.2 … 19 kg/m³
Pressure Range:
Maximum measuring range :
1… 10 bar (absolute)
Only argon (Ar) gas mixtures can be used with a maximum pressure of 9 bar (absolute).
Burst pressure: 30 bar
