Ultrasonic High temperature Liquid Flow Meter
Designed to accommodate temperatures up to 200°C, ALSONIC's high-temperature flow meter features a stainless steel, sealless sensor body that provides reliable measurement performance even under extreme temperature and pressure conditions.
Product Features
1. Suitable for water, water + glycol, deionized water and many other liquids
2. Measurement accuracy: ±2%
3. Virtually no pressure loss
4. Analog signal and bus communication are supported
5. Built-in temperature sensor
6. Bubble detection function
7. Ethylene glycol concentration measurement and compensation function
Downloads
Specifications
- Media: water, water-glycol mixture, oil and many other liquids
- Measurement accuracy: ±2% of reading
- Pressure: 0 – 40 bar
- Operating temperature: -40 to 200°C
- Wetted Material: Stainless steel 316L
- Connection: BSPP Male Thread (Flat Sealed)
- Output signal: Pulse, 0-5 V, MODBUS, 4-20 mA, IO-Link
- Function:
• Flow measurement
• Temperature measurement
-
Model：ALSONIC High Temp
